Name: Factory Good Quality Luxurious Electric 8 Function ICU Hospital Medical Patient Bed
Brand: Guangzhou Benray Medical Equipment Co., Ltd.
SKU: BR-HBE13
Price: 2,350.00 USD
Availability: InStock

Detail Information

Product:	8 Function Electric Hospital Bed	Model:	BR-HBE13
Safe Load:	250KG	Size:	Length (2120-2320) Width 1010* Height 640-860mm
MOQ:	1 Set	Delivery Time:	7 Days
Weighing Function:	Optional	X-ray:	Optional
One-click Reset;:	Yes

Product Description

8-Function Electric ICU Bed

BR-HBE13

Features:

1. Overall specifications: length (2120-2320) * Width 1010* height 640-860mm±10mm,Net length of bed (1930-2130) * Net width 820±10mm

2. The total length of the bed body is 2120-2320mm (with a hidden extension frame, it can be extended by 20cm, and the net width of the bed surface is 820 mm (the full width is 1010mm).

3. Safe load 250KG.

4. The whole bed is made of high quality cold rolled steel board.

5. The whole bed adopts multi-process "electro phoresis + powder" coating. After the second degree phosphating electrostatic spraying to ensure uniform coating.

6. The back board of the bed is X-ray for easy inspection. Embedded sponge mattress, PVC cover, waterproof and easy to clean.

7. Headboard and Foot board: removable headboard and tail board are blown by polypropylene resin. The head plate and tail plate are inserted fixing devices. In an emergency, it can facilitate disassembly and rescue, special care and safe handling of patients. And equipped with anti collision wheel device.

The head and tail plates are designed according to the ergonomic principle of the grasp handle, easy to promote.

8. Guardrail.

(1) In line with IEC 60601-2-52 standard, the new four-piece split lifting guardrail is installed on the bed panel, which can be moved at the same time with the function of the bed body to maximize the protection of patient safety. The upper part of the guardrail is easy to hold and can be used as a booster rod when the patient stands up. When the patient is examined or treated, the guardrail can be placed under the bed plate.

(2) Safety guardrail, guardrail can not be opened when subjected to internal and external pressure, and can be opened by external and internal pressure, effectively preventing patients from falling out of bed caused by private opening of the guardrail.

(3) The front and rear guardrail are set up angle display, can clearly show the back bed plate rising Angle and bed body tilt Angle.

(4) A nurse operation panel is set on the rear guardrail

(5) The electric CPR button is set on the rear guardrail to realize the electric CPR function.

9. Controller:3 Control mode

A.Touch screen control panel

B.Key board control panel built in the guardrail

a. Large icon button operation, can operate all bed positions and functions

b, with self-locking function, no operation, the guardrail remote control can be automatically locked to avoid misoperation

c.foot pedal control

10, On both sides of the bed, each set of manual CPR devices.

11,The four corners of the bed are equipped with an infusion stand jack and a stainless steel infusion stand.

12,Diameter 150mm double-sided caster, anti-corrosion, good acid resistance, quiet, anti-winding, central control side brake, easy and simple braking

13, The standard battery, can provide the power required for position adjustment in the case of power failure.

14, The use of "Denmark" imported motor performance is stable and reliable, no noise pillar motor; Column type linear lifting structure.

15, Weighing touch screen function (optional)

(1). Accuracy up to 0.01KG.

(2). Maximum weight 250KG.

16, 7 inches above the touch screen display function.

(1). The touch screen has the function of hospital bed instruction.

(2). Touch screen with weighing display, weighing button operation, data storage and other functions. Data storage capacity is greater than 1000 patient weight data.

Parameters

Product	Hospital 8 Function ICU Bed
Position adjustment function	back rise 0-70 °
Foot rise	0-18°
Height lifting	64-86cm
Trendelenburg	0-10°
Anti-trendelenburg	0-10°
The whole bed tilts to the left	0-10°
The whole bed tilts to the right	0-10°
Foot Part	0~-88°
Heart chair position	Yes
One-click reset;	Yes
Weighing function	Yes
Patient out of bed alarm function	Yes
Synchronous linkage	Yes
Foot board extension	Yes
X-ray /C arm	Yes

Factory Good Quality Luxurious Electric 8 Function ICU Hospital Medical Patient Bed 3

Factory Good Quality Luxurious Electric 8 Function ICU Hospital Medical Patient Bed 4

Customer Visit & Feedback

Factory Good Quality Luxurious Electric 8 Function ICU Hospital Medical Patient Bed 5

Factory Good Quality Luxurious Electric 8 Function ICU Hospital Medical Patient Bed 6

Factory Good Quality Luxurious Electric 8 Function ICU Hospital Medical Patient Bed 7

Factory Good Quality Luxurious Electric 8 Function ICU Hospital Medical Patient Bed 8

FAQ

Q: Where is your company located in? Can I have a visit?

A: Our company is located in Guangzhou, China. We are glad to invite you to come to our office and have a face-to-face talking before placing orders.

Q: Do your products have quality assurance?
A: Yes.We have more than 10 years’ experience in making dental unit. Our products have been exported to more than 30 countries.

Q: How about the discount ?
A: To guarantee the good quality, both raw material and manufacture have cost us much. We can offer some discount if the quality is large enough.

Q: How long is warranty for items?
A: 1 year and we can provide accessories replacement if it is damaged during the warranty period.

Q: Could you print LOGO for items?
A: Sure. We can offer printing LOGO as your request.

Q: Do you have CE approved?
A: Yes. Most of our products have CE, TUV and ISO certifications.

Place of Origin:	China
Brand Name:	Benray Medical
Certification:	CE,ISO,TUV
Model Number:	BR-HBE13

Minimum Order Quantity:	1
Price:	USD2200/Set ~ USD2500/Set
Packaging Details:	Carton
Delivery Time:	5-8 working days
Payment Terms:	Western Union, MoneyGram, T/T
Supply Ability:	5000pcs/Month
