X-ray Generator
Generator Type: High Frequency Inverter 80kHz
Input Power: Single phase 220VAC, 50/60Hz
Radiographic Ratings: Small Focal Point 20-35kV/10-100mAs
Power Rating: 1.8kW
X-ray Tube
Model: Fixed anode, China Hangzhou XD7
Focal Spot Size: Dual Focus 0.5mm
Target Material: Molybdenum (Mo)
Port Material: Beryllium (Be)
Anode Heat Storage: 35kJ
Anode Cooling: Air cooling
Filtration: Mo（0.03mm）, Al（0.5mm）
Radiographic Stand
C-ARM: Vertical Movement: 580mm
Rotations Deg: +175°～-180°
SID: 650mm
Cassette Image Receptor
18×24cm
Line Voltage: 220Vac@15A,Single phase
Weight: 240kg
